Anindita Shrivastava

Sections and elevations

Cuts through the buildings show how rooms stack, how light reaches them and how life moves between levels. Elevations show the face each building turns outward.

The Health Sanctuary

3 drawings

Sectional perspective of The Health Sanctuary: stacked rooms, greenhouses and gardens, each filled with residents and carers. — Sectional perspective showing healthcare, domestic life and shared activity around planted greenhouse volumes on several levels.

Colour section through a five-storey building with glazed pitched roofs, a planted central greenhouse and small rooms with people inside. — Section through the sanctuary showing clinical and domestic rooms, landings and shared activities connected by planted greenhouse volumes.

Elevation of a row of timber homes and glazed greenhouses with small figures in the windows. — Frontage study showing domestic and clinical rooms beside planted greenhouse volumes, with individual and shared activities along the edge.

Sattva: The Healing Village

1 drawing

Three landscape sections showing villas, gardens, compost pits and aquaponics. — Sections link the villas to seasonal gardens, aquaponics and bird-watching areas.

The Food Park

1 drawing

Section through a growing tower with planting, kitchens and rooms. — Section through a growing tower: planting, kitchens and the rooms around them.

The Garden Hotel

4 drawings

Colour section of the hotel showing restaurants, a courtyard pool, green gathering spaces and guest rooms, with form, facade and room diagrams below. — Perspective section depicting the space design of each fragment of the building and the nature pockets at different levels.

Circular cut-out of the hotel facade with guest rooms, planted terraces and people. — The facade: green voids give permeability between nature and guests.

Circular cut-out of a double-height restaurant with pendant lights, a tree and people at tables. — The signature restaurant.

Concrete hotel frontage with framed rooms, planted ledges and guests on a walkway. — The frontage with green voids.

Group Housing

2 drawings

Two building sections and elevations with people on balconies and in rooms. — 2 BHK and 3 BHK units in section and elevation.

Circular elevation of stacked duplex units with terraces, climbing plants and string lights. — 4 BHK duplex unit massing.

Modern Dome

1 drawing

Section of a dome-shaped bazaar with stepped seating, a market below and hot-air balloons above. — Section through the Modern Dome.

Mixed Use Development

2 drawings

Section of a tall tower with labelled commercial, office, service and residential floors. — Sectional elevation: commercial, office, service and residential floors.

Circular section through stacked floors with tables, trees and gardens, in navy and white. — Section through the office and garden floors.
